oxygen O2 gas monitor/detector-G10
oxygen O2 gas monitor/detector-G10
oxygen O2 gas monitor/detector-G10
oxygen O2 gas monitor/detector-G10
oxygen O2 gas monitor/detector-G10
oxygen O2 gas monitor/detector-G10

oxygen O2 gas monitor/detector-G10

    • Upload to computer function
    • Using advanced ultra-low energy micro component
    • Ultra bright LCD display
    • Ultra small ergonomic design
    • Sensor fault self-test, automatic calibration function
    • Replaceable insert sensor module
    • Two levels triple alarms (sound, light, vibration)
    • Sound and light alarm can be clearly identified
    • Mini size and high accuracy
Product description

The portable oxygen detector is a kind of essential safety instrument which can continuously detect the oxygen concentration in the working environment.It is suitable for explosion-proof, toxic gas leakage, underground pipelines or underground mines and other places, can effectively ensure the safety of the staff's life is not infringed, the production equipment is not lost. This O2 detector is applicable to the concentration of oxygen in the ambient air detection, are widely used in metallurgy, power plant, chemical, mine, tunnel,underground pipelines and other places, effective prevention of hypoxia and oxygen poisoning.

G10 is one waterproof gas detector that adopts imported sensors, the quality is stable and reliable. With leading operation menu, 1700MA rechargeable lithium batteries, and replaceable inserted gas sensing module, our G10 works in environment of -20°C to 70°C, and for its features such as explosion-proof, waterproof and dustproof etc.



Choose one gas that you want to test with this machine from the below gases list;

Gas

Measuring range

Optional range

Resolution

Response time

 EX(LEL)

0-100%LEL

0-100%VOL (infrared)

1%LEL/1%VOL

≤15second

 O2

0-30%VOL

0-30%、0-100%VOL

0.1%/0.01%VOL

≤15second

H2S

0-100PPM

0-50、200、1000PPM

0.1/1PPM

≤15second

CO

0-1000PPM

0-500/2000/5000PPM

0.1/1PPM

≤15second

NO2

0-20PPM

0-50、1000PPM

0.1/1PPM

≤20second

Natural gas

0-100%LEL

0-100%VOL

1%LEL/1%VOL

≤15second

NOX

0-20PPM

0-50、1000PPM

0.1/1PPM

≤20second

CH4

0-100%LEL

0-100%VOL

1%LEL/1%VOL

≤15second

 CO2

0-5000PPM

0-1%、5%、10%VOL (infrared)

1PPM/0.01%VOL

≤20second

NO

0-250PPM

0-500、1000PPM

1PPM

≤20second

N2

0-100%VOL

0-100%VOL

0.1%VOL

≤15second

Alcohol

0-100%LEL

0-100%LEL

1%LEL/1%VOL

≤15second

SO2

0-20PPM

0-50、1000PPM

0.1/1PPM

≤20second

CL2

0-20PPM

0-10、50、100PPM

0.1PPM

≤20second

dichlorosilane

0-20PPM

0-20、100PPM

1/0.1PPM

≤20second

NH3

0-100PPM

0-50、500、1000PPM

0.1/1PPM

≤20second

Silicon tetrachloride

0-20PPM

0-20、100PPM

1/0.1PPM

≤20second

H2

0-1000PPM

0-40000PPM

1/10PPM

≤20second

PH3

0-20PPM

0-20、1000PPM

0.1/1PPM

≤20second

 HCL

0-20PPM

0-20、50、100PPM

0.1/1PPM

≤20second

Acrylonitrile

0-100PPM

0-100PPM

1PPM

≤20second

TVOC

0-100PPM

0-100PPM

1PPM

≤20second

CLO2

0-50PPM

0-10、100PPM

0.1PPM

≤20second

HCN

0-50PPM

0-100PPM

0.1PPM

≤20second

 ETO

0-10PPM

0-100、1000PPM

1PPM

≤20second

 O3

0-10PPM

0-20、100PPM

0.01/0.1PPM

≤20second

 CH2O

0-20PPM

0-50、100PPM

0.1/1PPM

≤20second

 F2

0-10PPM

0-1、10PPM

1/0.1PPM

≤20second

 HF

0-10PPM

0-1、10、50、100PPM

0.01/0.1PPM

≤20second

Xylene, toluene

0-20PPM

50、100PPM

0.1/1PPM

≤20second

Stench

0-100PPM

0-100PPM

1PPM

≤20second

For unlisted gas, please contact with our sales department!



Main function
  • Ultra bright LCD display
  • Ultra small ergonomic design
  • High waterproof design
  • Sensor fault self-test, automatic calibration function
  • Replaceable insert sensor module
  • Two levels triple alarms (sound, light, vibration)
  • Sound and light alarm can be clearly identified
  • Casted plastic shell
  • Antiskid, waterproof, dust proof, explosion proof



Technical index

Test gas

Oxygen(O2)

Range 0-30%vol
Resolution 0.1%vol

Accuracy

3%F.S

Response time

T90<10s

Indication mode

LCD display

Alarm indication

Light emitting diode, sound, vibration

Detection mode

Diffusion ( non pumped)

Working environment temperature

 -20 -70℃ ,Humidity<95%RH no condensation

storage

6000 alarm records inquiry function

Power

3.7V 1700MA rechargeable lithium battery

Working hours

Lasting for 300 hours

Grade of protection

IP65

Certification mark:

Ex ib IIB T3 GB

Explosion proof:

No: CNEx19.3459x

Weight

Around 132g (including battery and accessories)

 Size

100mm*58mm*30mm
